Baumer PXU-120M.Q Mono, USB3.0, 4248×2832px, 13.8fps Camera

• 2 x Redundant MIL-STD-1553 Channels
• 8 x ARINC-429/575 Tx/Rx Channels
• 8 x RS-232/422/485 Sync/Async Serial Channels
• 28 VDC Input PSU with 50 ms holdup option

• 1-2 Dual Redundant, Independent MIL-STD-1553 Busses (channels) and/or 8 ARINC-429 Channels
• Same Full Features as PCIe Interface Cards, Including Hardware Interrupts!
• Variable Voltage 1553 Optional
• Flash Disable Factory Setting for Secure Memory
• 6 SE Avionics Discretes, One RS-485 Discrete, TTL Clock, Triggers
• Windows 10 Only – Contact Factory for Linux
• Weight: 185g. Dimensions: 110x89mm (Including Rugged Mounting Plate)
• Commercial Temp (0-60C)
• Signal Capture on First 1553 Channel, and First Two ARINC RX Channels
• AltaView and AltaRTVal Windows Application Optional
• Includes AltaAPI and AltaAPI-LV (LabVIEW) Development Kits

USB Small, Rugged Interface for 1-2 MIL-STD-1553 channels. In-Line (NLINE) for lab or rugged deployment!

• One or Two Independent, Dual Redundant 1553 Busses
• Full BC, RT and BM Controls. Operational Read & Write Capability While Transmitting.
• Auto Load BC, RT and BM Images for Fast Startup
• IRIG-B RX Decode
• Avionics Inputs for MIL-STD-1760 RT Addressing.
• USB SuperSpeed 3.0. Compatible with USB 2
  • Recommend USB 3.0 SuperSpeed (SS Trident Logo) for all applications. ~5-10K Packets/Sec Total.
  • USB 2.0 for slow bus rates only. Hubs are not recommended
• AltaAPI SDK Provides Easy Integration – Quickly code your application with our modular, portable Windows & Linux SDK. Single application only, and other applications may affect performance.

• -5 Independent, Dual Redundant (A/B) MIL-STD-1553 Channels and Optional 8 ARINC Channels
• 8 ARINC Channels: 4 Shared RX/TX & 4 RX
• Ideal for Advanced Test or Embedded Applications
• Commercial, Extended Temp/Rugged/Conduction Cooled
• **Signal Capture on First Channels – Standard**
• P4/P6 Rear Panel I/O & XMC 2.0 Connectors Optional
• 512 KByte, 32-bit RAM per 1553/ARINC Device
• Up to 2 ARINC 717 RX and TX Channels
• Avionics and RS-485 Discretes
• Full 1553 and ARINC Controls Like Other Alta Cards.
• Dual and Full Function 1553 Channels.
• Programmable ARINC Bit Rate (500-200K), Bit Encoding, Bits Per Word, Start/Stop and Parity
• Encode/Decode Almost Any ARINC-429 PHY Signal
• Start-up, Loop-Back, User and Periodic BIT
• Dual Temperature Sensors
