Description
Surveillance NoxCore HD for Enhanced Situational Awareness
The Surveillance NoxCore HD is built to meet the growing demand for high-resolution thermal imaging in modern surveillance and security operations. Designed with the latest NoxEngine technology, this infrared camera core delivers exceptional image clarity and performance, enabling operators to detect and analyze targets with greater precision.
With its high-definition resolution and wider field of view, the Surveillance NoxCore HD significantly improves situational awareness compared to standard definition systems. This allows users to monitor larger areas while maintaining the ability to identify critical details, making it ideal for law enforcement, border control, and maritime surveillance applications.
High Performance Thermal Imaging
At the core of the Surveillance NoxCore HD is a cooled MWIR detector that ensures accurate and reliable thermal imaging in challenging conditions. The rotary Stirling cooling system enhances sensitivity and reduces noise, resulting in clearer images even in low contrast or low visibility environments.
The camera core is optimized for performance and efficiency, offering a compact footprint and low power consumption. This makes it suitable for integration into mobile platforms, fixed installations, and airborne systems. Its rugged design ensures consistent operation in extreme temperatures and demanding environments, supporting long-term reliability.
Seamless Integration
The Surveillance NoxCore HD is designed with integration flexibility in mind. It supports multiple video output formats, including HDMI with optional SDI or analog configurations. Streaming capabilities via GigE Vision and Ethernet-based control ensure compatibility with a wide range of modern systems and software platforms.
With standardized interfaces and easy configuration options, system integrators can quickly deploy the Surveillance NoxCore HD into their existing infrastructure. Its adaptability and advanced imaging capabilities make it a dependable solution for complex surveillance missions.
Technical Specifications
| Parameter | Specification |
| Spectral Range | 3 µm to 5 µm (MWIR) |
| Detector Type | Cooled snapshot FPA |
| Resolution | 1280 x 720 pixels |
| Pixel Pitch | 10 µm |
| Optical Aperture | f/4 |
| Cooling | Rotary Stirling |
| Cooldown Time | < 6 minutes at 20°C |
| Power Consumption | < 20W steady operation |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +70°C |
| Video Output | HDMI 720p, optional SDI or analog |
| Streaming | h.264 via RTSP or UDP, RAW via GigE Vision |
| Control Interfaces | RS232, Ethernet IP |
| Vibration Resistance | 2g operational |
| Shock Resistance | 25g operational |
