NoxCam HSI Infrared Camera for High Performance Thermal Imaging
NoxCam HSI Infrared Camera is engineered to deliver advanced radiometric thermal imaging for professionals who demand precision, speed, and flexibility. Designed with a robust and compact housing, this camera performs reliably in harsh industrial and environmental conditions while maintaining exceptional imaging accuracy.
At the core of the NoxCam HSI Infrared Camera is advanced detector technology powered by the latest generation NoxEngine. This enables high sensitivity imaging across multiple spectral bands, including short wave, mid wave, and long wave infrared. With radiometric calibration built into the system, users can obtain highly accurate temperature measurements across a wide range, making it ideal for applications such as non destructive testing, thermography, and scientific research.
One of the key advantages of the NoxCam HSI Infrared Camera is its flexibility. The system supports multiple configurations tailored to specific project requirements. Users can select from various resolutions, frame rates, and optical setups depending on their application. The integrated optical filter wheel enhances imaging capabilities by enabling spectral selection for more detailed analysis.
The camera also features embedded recording capabilities, allowing users to capture radiometric data directly onto a removable SSD. This ensures efficient data management and simplifies workflow in both laboratory and field environments. Additionally, compatibility with widely used software platforms such as Matlab, ImageJ, and Labview ensures seamless integration into existing analysis pipelines.
High speed imaging capabilities make this camera suitable for dynamic thermal events, while its synchronization input allows precise alignment with external triggers. Combined with its rugged design and advanced functionality, the NoxCam HSI Infrared Camera offers a complete solution for high performance thermal imaging across industrial, scientific, and defense applications.
Technical Specifications
| Parameter | Specification |
| Detector Type | Cooled snapshot FPA and TEC cooled options |
| Spectral Bands | SWIR 0.9 – 1.7 µm, MWIR 3 – 5 µm, LWIR 7.7 – 11.5 µm |
| Image Resolution | 640 x 512, 1280 x 720, 320 x 256 pixels |
| Pixel Pitch | 10 µm, 15 µm, 30 µm |
| Frame Rate | Up to 355 Hz, higher in sub window mode |
| Temperature Measurement Range | Configurable from sub zero up to 3000 °C |
| NETD | Typical 18 mK |
| Optical Aperture | f 1.5 to f 5.5 depending on model |
| Lens Compatibility | 12 mm to 200 mm and microscope lenses |
| Data Interface | GigE Vision, GenICam, optional Camera Link |
| Recording Format | Radiometric RAW, H.264 |
| Storage | Removable 2.5 inch SSD |
| Video Output | HDMI 720p, optional SDI |
| Operating Systems | Windows, Mac OS, Linux |
| Applications | NDT, thermography, industrial inspection, scientific imaging |
